LSS vertical fuel gas steam boiler

LSS vertical fuel gas steam boiler

  • 所属分类:Environmental protection boiler

  • 点击次数:
  • 发布日期:2021/04/25
  • More
  • Message
Detailed

LSS vertical fuel gas steam boiler

Features:

1. Fast steam production: small water volume, rapid heat transfer, rapid temperature rise and pressure rise. The required steam can be supplied 5 minutes after the ignition is started, and it is equipped with a high-efficiency steam-water separator to ensure the high quality of steam.

2. Automatic control and safe operation: The vertical tubular boiler adopts automatic control, which is easy to operate. Once the ignition is started, the boiler runs automatically. After combustion, it will automatically ignite, extinguish, and automatically feed water. The water level, temperature and steam pressure are automatically adjusted and protected to ensure safe operation and safety.

3. Convenient installation: the boiler adopts a vertical layout, the boiler has a compact structure and a small floor area; the pressure rises quickly and the safety is good. Therefore, the boiler room requirements are simple. The boiler as a whole is assembled, debugged and fully equipped in the factory. After the boiler is installed in place, it can be put into operation only by connecting water, electricity, oil, gas and sewage pipes.

4. Good sealing performance: The entire flue gas channel is inside the boiler body, which is safe.

5. High thermal efficiency: An energy saver can be arranged at the boiler flue gas outlet to further reduce the exhaust gas temperature and increase the boiler efficiency by more than 2%.

6. Good matching of the combustion system: The selected internationally renowned brand burners have high coal burning efficiency, improve boiler efficiency and save operating costs to the greatest extent.

7. The outer packaging material is light in weight, has good heat preservation effect, small heat loss, and beautiful appearance. If the customer has special requirements for the shape and color, please explain to our factory.


Application range:

Supporting food baking equipment, ironing and washing equipment, special boilers, industrial boilers, clothing processing equipment, food and beverage processing equipment, sterilizer dryers, homogenizers

Equipment, distillation equipment, complete chemical equipment, pharmaceutical equipment, heat exchange refrigeration and air conditioning equipment


催化剂储罐

【 LSS系列立式燃油,燃气蒸汽锅炉—技术参数 】

锅炉型号Boiler Type

单位

LSS0.3

LSS0.5

LSS1.0

LSS1.5

LSS2.0

参数
parameters

额定蒸发量
Rated Output

t/h

0.3

0.5

1.0

1.5

2.0

额定蒸汽压力
Rated Steam Presusser

MPa

0.7,1.0,1.25,1.6

蒸汽温度
Steam Temperature

170,184,194,204

给水温度
Feed Water Temperature

20

燃烧调节方式
Type of Burning


一段火On-Off

二段火
Hi-Low-Off

锅炉热效率
Thermal Efficiency

%

>90

>94

适用燃料
Apply Fuel


轻油,天然气
、Light Oil、Natural Gas

燃料耗量
Fuel Consumption







轻油Light Oil
kg/h

20

33

70

106

140

天然气Natural Gas
Nm3/h

24

41

84

121

162

主蒸汽口
Steam Outlet


DN40

DN50

DN65

DN80

DN80





























尺寸

L

mm

1600

1600

1900

2300

2300

W

mm

1380

1380

1600

2000

2000

H

mm

1900

2810

3400

3500

3500
